※ With backlight.
※ Timing function for spray cycle.
※ With oil pressure memory function.
※ Electronic settings for oil pressure regulation.
※ High precise control panel with contact spring.
※ Ultrasonic bath with digital timer.
※ Deluxe trolley with independent on-vehicle cleaning function.
※ Operational capability: Carry out the following tests manually or automatically by selecting the modes: real simulation of spray
angle, leak, spray,delivery volume, equalisation and spray cycle.
※ Test range: Revolutions: 0-9950r/min, Pulse width: 0-20ms, Meter pulse: 0-9950 times, corresponding combinations timing, with
standard testing programs for automatic testing and cleaning providing thousands of testing program combinations.
※ Unique test mode: Change setting values freely, simulating the working condition of engine, load signal feedback, terminate or
resume the program during test, latest high precision countdown timer and counter.
※ Built-in memory program: Diagnose the changes of a group of injectors before and after cleaning.
※ Control panel: Simple and easy to operate touch panel.
※ Injector protection: With automatic constant current and voltage control device, current and voltage regulated automatically, enables
testing and cleaning for various injectors such as high resistance, low resistance, voltage type and current type.
※ Protection system: With minimum and maximum fluid level backflow device, high-low fluid level viewing window, over-heat
indicator, alarm for inflammable gas concentration and automatic injector anti-overflow device.
※ Open/close cycle test: Capable of testing the minimum open/close cycle of injectors to identify the quality of the injectors.
※ Various adapters: Optional variety of adapters are suitable for different types of injectors including standard, Hose/Tail type, K type,
TBI type.Designed and manufactured as per user's requirements are available.
※ Cleaning system: Test and clean one or more injectors at one time, reverse cleaning and ultrasonic cleaning.
※ Deluxe trolley with separated on-vehicle cleaning feature.
※ Automatic recycle system for testing fluid.
|
Input Voltage
RPM
Pulse Width
Count
System Pressure
|
200-240V 50~60Hz
0~9950r/min, 50r/min (step)
0~20ms/min, 0.1ms (step)
0~9950, 50 (step)
0~6.5kg/cm2 variable regulation
|
Due to the continuous innovation and upgrade, our products' features may be updated.
Please refer to actual products or contact us for more information.
